Synthrotek is pleased to offer a complete line of eurorack synthesizer modules, power, cases and accessories in both complete units kits and panels & pcbs. We now offer a very complete analog modular monophonic voice with many accompanying utility modules. This new complete voice is the product of a collaboration with synth guru George Mattson, who now joins us in releasing our new MST (Mattson – Synthrotek) line of premium modules.
The MST Audio/CV 4-Channel Mixer is a mixer and/or attenuator with mute switches per channel – A must for the performing modular artist!
1 on/off (mute) switch per channel
Jumper select ~unity gain or ~2x gain amplification
Attenuator per channel
Master output attenuator
Normal- in-phase output & Inverted, reverse-phase output
Green +5V LED indicates “Optimal” level output
Red “Clip” LED indicates ~8V to rail
Current draw: V+ max 13.25mA, V- max 7.35mA
Width: 8HP, Depth: 3.5 cm (1.88 in)
